Features
- RTT 10E4 – 10E6 ohms per ESD-S7.1
- Conductive – able to remove electrostatic charges to ground
- Exceeds ANSI/ESD S20.20 minimum recommended technical requirements of < 1 x 10E9 ohms for ESD Protected Flooring and suitable for ESD protective flooring
- Can be component in Flooring – Footwear System as primary grounding method (<3.5 x 10E7ohms per ANIS/ESD STM 97.1)
- Areas greater than 20 square feet do not require expensive grounding grids or wires; Static Charge Decay: dissipates 5000 volts to zero in <0.01 sec per FTMS 101C/4046
Can replace ESD floor mats in electronics, manufacturing, assembly, and test areas protecting ESD susceptible items - Adheres to floors, walls, or wood furniture
Provides ESD protective surface on concrete and epoxy floors and in places which are difficult to protect - Excellent wear and durability
Excellent value providing long-life - Apply via rolling or spraying
Productive application and maintenance; easy cleanup - Two colors to choose from
Grey hides dirt better in most applications; Light Grey brightens up factory area - RTT: 10E4 – 10E6 ohms per ESD S7.1 @ 50% R.H.
- 2 coats are recommended to obtain RTT: 10E5 ohms per ANSI ESD-S7.1 RTG 10E5 ohms per ANSI ESD-S7.
- Coverage: 300-400 sq. ft/gallon
Excellent value - This product has been certified to meet the RoHS requirement.
- Lead-free RoHS compliant
- Made in The United States of America
- Note: ESD protected flooring requires a path-to-ground from carts or equipment & ESD footwear on personnel to remove electrostatic charges.
Technical Info
- TB-7001 – Statguard ® Conductive Acrylic Paint – Application Instructions and MSDS
- TB-7001 – MSDS, Statguard ® Conductive Acrylic Paint
